MT
Miniature T5 Strip Fixture
Technical Data
Features
· Miniature 1 ½" Wide X 1 ½" High Profile with High Lumen Output.
· Perfect for concealed source applications in valences, coves and casework.
· Reflector options offer the ultimate in application versatility.
· Precision formed, rigid housing.
· Aluminum construction standard.
· GE Premium Ballasts: Normal and High (HO) options available.
· Electronic Ballast for flicker-free performance.
· Combine with GE Lamps for extended Lamp/Ballast Warranty.
· Universal Input Voltage Standard.
· Reflectors offer up to 98% reflective materials.
· Can be customized for specific applications.
· Proudly Made in West St. Paul, Minnesota, USA!
Meets or Exceeds
1598 Standard
Series
Energy Solutions International
1.5"
2.4"
1.5"
1X2
1X3
1X4
1X6
1X8
22.4"
34.3"
46.0"
68.6"
94.0"
Reflector
Profiles
Ordering
Photometrics
Part Number = Size + Style + Profile + Material + Ballast
(Example F-14MT5SNEAH = 1'x4' Miniature Strip with a standard, normal enhanced alum. reflector and HO ballast)
Size
F-12MT5 - 1' x 2'
F-13MT5 - 1' x 3'
F-14MT5 - 1' x 4'
F-16MT5 - 1' x 6'
F-18MT5 - 1' x 8'
Profile
N - Normal
F - Focused
W - Wide
T - Tight
S - Shield
D - Downlight
Material
EA - 95% Enhanced
WR - 92% White
MM - 95% Diff. Alum.
WO - 98% White Optic
Ballast
N - Normal
H - High (HO)
Style
S - Standard
A - Asymmetric
C - Cover
(888) 308-9197
Report No. - F-14MT5WRCN
Efficiency - 97.0%
Photometric files available by request
Spacing Criteria - 2.20
A4
