illumination
steel socket bars
lock lampholders
reflector profile
Prepunched for lampholders and wire passage-
way. Completely covers the ends of the existing
fixture to provide a clean, seamless appearance.
reflective white enamel. The substrate is 0.020"
high quality aluminum. The reflector profile is
optimized using computer analysis and manufac-
tured using state of the art CNC equipment. A
protective premask is applied to all reflective sur-
faces prior to manufacture.
and socket bars are removed. With the new bal-
last installed, the ESI endplates are centered at
the ends of the fixture and secured with self-tap-
ping screws. The side reflectors are attached with
a tab-lock system. The center reflector is secured
with quarter-turn fasteners and provides tool-free
ballast access.
performance, architecturally styled luminaires
factory for other applications
