High Bay Luminaire
Meets or Exceeds
1598 Standard
Series
Energy Solutions International
Technical Data
Housing: 20ga. (0.032") pre-painted steel die
formed with sufficient knockouts for mounting and
electrical supply.
Finish: All cold rolled steel parts are painted with
a smooth, glossy, highly reflective white paint.
Reflector: Can be ordered with a 95% specular,
a 85% specular, or a 92% diffuse white enamel.
Substrate is 0.020" high quality aluminum. The
reflector profile is optimized using computer anal-
ysis and manufactured using state of the art
CNC equipment. A protective premask is applied
to all reflective surfaces prior to manufacture.
Construction: The solid body provides added thermal
management and added rigidity. The socket bars
attach to the body with a locking tab and quarter-turn
fastener. Reflector is secured to the socket-bars with
screws.
Mounting: Fixture is designed for suspended applica-
tions
Features
A Breakthrough Alternative to 1000 Watt HID
High-Bay Systems
Superior Light Quality, Maximum Photometric Efficiency
Superior Thermal Management
Available with Wireguard and Lens
Installation
Ordering Information
Size
F-34AZ - 3' x 4'
Part Number = Fixture Size + Reflector Material + # Lamps + Lamp Wattage + Voltage + Ballast Type + Options
(Example F-34AZEA1254UNV = 3'x4' AZ Series High Bay with an 95% alum. reflector, 12-54W lamps, and a universal voltage ballast)
Reflector
EA - 95%Enhanced Alum
WR - 92% White Enamel
# Lamps
10
12
Lamp Watts
54
Voltage
480
UNV
Options
N - Normal
H - High Ballast Factor
L - Low Ballast Factor
WG - Wire Guard
CL - Clear Lens
48.0
"
