HS
High Bay Luminaire
Meets or Exceeds
1598 Standard
Series
Energy Solutions International
17.625
"
3.875
"
2x4 Profile
48.000
"
Quality, cam-lock
lampholders
Solid, 0.032" steel body provides
superior rigidity and durability
Hinged design allows ballast
access with lamps installed
Technical Data
Housing: 20ga. (0.032") pre-painted steel die
formed with sufficient knockouts for mounting and
electrical supply.
Finish: All cold rolled steel parts are painted with
a smooth, glossy, highly reflective white paint.
Reflector: Can be ordered with a 95% specular,
a 85% specular, or a 92% diffuse white enamel.
Substrate is 0.020" high quality aluminum. The
reflector profile is optimized using computer
analysis and manufactured using state of the art
CNC equipment. A protective premask is applied
to all reflective surfaces prior to manufacture.
Construction: The solid body provides added rigidi-
ty. The socket bars attach to the body with a locking
tab and quarter-turn fastener. Reflector is secured
to the socket-bars with screws.
Mounting: Fixture is designed for surface, pendant
mount, or suspended applications
Features
A Breakthrough Alternative to HID
High-Bay Systems
Superior Light Quality, Maximum Photometric Efficiency
Available in T8 and T5 lamp configurations
Hinged reflector allows tool-free ballast maintenance
with lamps installed
Highlights
12.000
"
3.875
"
1x4 Profile
(2 - 4 Lamps)
(4 - 6 Lamps)
24.000
"
3.875
"
3x4 Profile
(8 - 12Lamps)
Installation
I4
