Installation
6.75
"
5.75
"
51.75
"
Technical Data
Housing: The glass fiber reinforced polyester
housing provides exceptional strength and rigidity.
The poured in place gasket seals the enclosures
from the most hostile environments.
Lens: 100% Virgin Impact Resistant Acrylic.
Reflector: Can be ordered with a 95% specular,
a 85% specular, or a 92% diffuse white enamel.
(For maximum performance, 95% specular is rec-
ommended.) Substrate is high quality aluminum.
The reflector profile is optimized using computer
analysis and manufactured using state of the art
CNC equipment. A protective premask is applied
to all reflective surfaces prior to manufacture.
Construction: Electrical components are mounted to
an integrally hinged gear tray. No tools are required
for ballast access. Captive stainless steel latches
secure the lens.
Mounting: Stainless steel brackets are compatible
with surface mount and cable mounting systems.
Features
Specially designed to minimize glare while providing
wide distribution lighting to meet the demands of parking
facilities
High-performance vapor proof luminaire
Utilizing the latest in LED T8HO tube technology
Durable construction, stainless-steel latches
PG
Glare Reduction Parking Garage Luminaire
Meets or Exceeds
1598 Standard
Series
Energy Solutions International
Ordering Information
Part Number = Fixture Series + Light Engine + Lamp Color + Voltage
(Example F-14PGEA2L-LED-PC-850-DIM - 1x4 LED PL Series, 2 Lamp, Polycarb Latches 850 color temperature)
Series
K-12PG - 1'x2'
K-14PG - 1'x4'
F-12PG - 1'x2'
F-14PG - 1'x4'
Reflector
EA - Enhanced Aluminum
Number of Lamps
2L - LED
3L - LED
1L - LED
Output
835 - LED 35K Color Temp
841 - LED 41K Color Temp
850 - LED 50K Color Temp
Options
SS - Stainless Latches
PC - Polycarbonate latches
480 - 480 Step Down Transformer
I22
