Energy Solutions International
Meets or Exceeds 1598 Standard
Ordering Information
Size
14EW - 1' x 4'
18EW - 1' x 8'
Part Number = Fixture Size + Reflector Material + # Lamps + Lamp Wattage + Voltage + Ballast Type + Options
(Example 14EWEA454UNV = 1'x4' Extra Wide Strip with an enhanced aluminum reflector, 4-54W lamps, and a universal voltage ballasts)
Reflector
EA - Enhanced Alum
# Lamps
3
4
6
8
Lamp Watts
54
Voltage
120
277
UNV
Photometrics -
Wide Distribution (4) 54W
.ENERGY SOLUTIONS 1 X 4 FLUORESCENT LUMINAIRE
WITH WHITE HOUSING AND SPECULAR ALUMINUM REFLECTOR
FOUR T5 LINEAR FLUORESCENT 54 WATT LAMPS, LUMEN RATING 5000 LMS. ONE SYLVANIA
QTP 4x54 BALLAST OPERATING AT 277 VAC AND 231 WATTS
13.25
1.60
CANDLEPOWER SUMMARY
ZONAL LUMENS AND PERCENTAGES
** EFFICIENCY = 93.6% **
PAINT REFLECTANCE = 0.78 S/MH = 2.50
SC (ALONG) = 1.40 SC (ACROSS) = 2.50
PREPARED IN PHOTOPIA FOR
ENERGY SOLUTIONS
ST. PAUL, MN
LUMINANCE SUMMARY - CD./SQ.M.
Photometrics -
Wide Distribution (3) 54W
.ENERGY SOLUTIONS 1 X 4 FLUORESCENT LUMINAIRE
WITH WHITE HOUSING AND SPECULAR ALUMINUM REFLECTOR
THREE T5 LINEAR FLUORESCENT 54 WATT LAMPS, LUMEN RATING 5000 LMS. ONE SYLVANIA
QTP 4x54 BALLAST OPERATING AT 277 VAC AND 176 WATTS
13.25
1.60
CANDLEPOWER SUMMARY
ZONAL LUMENS AND PERCENTAGES
** EFFICIENCY = 94.9% **
PAINT REFLECTANCE = 0.78 S/MH = 2.38
SC (ALONG) = 1.29 SC (ACROSS) = 2.38
PREPARED IN PHOTOPIA FOR
ENERGY SOLUTIONS
ST. PAUL, MN
LUMINANCE SUMMARY - CD./SQ.M.
