GTAR
T5 Direct-Indirect Troffer
Installation
47.750"
23.500"
Lens provides soft
illumination
Solid, 0.032" gloss white
steel components
High-quality,
twist-lock
lampholders
Computer designed
reflector profile
Technical Data
Features
High performance, architecturally styled
luminaire
Provides soft, even illumination
Available in 1, 2, and 3 lamp
configurations (T5 and T5HO only)
Highlights
5.250"
Meets or Exceeds
1598 Standard
Series
Energy Solutions International
Housing: 20ga. (0.032") pre-painted steel die formed with sufficient
knockouts for mounting and electrical supply.
Finish: All cold rolled steel parts are painted with a smooth, glossy,
highly reflective white paint.
Construction: The solid ten-bend body provides added rigidity. The endplates
are securely fastened to the fixture body. The top mount ballast cover is
secured with four screws.
Mounting: Fixture is designed for lay-in installations only
C8
