LX
Direct-Indirect LED Troffer Luminaire and Kit
ETL Pending
Series
Energy Solutions International
47.75
Matte White Aluminum
Construction
Thermally Managed, Long-life
LED Light Engine
Linear Ribbed Lens with
Optical Liner
Technical Data
Housing: All aluminum construction minimizes
weight and maximizes thermal performance of
the LED light engine.
Finish: All parts are painted with a matte white
paint to provide soft, even illumination.
New Fixture Mounting: Fixture is designed for
lay-in, recessed applications only
Retrofit Instructions: The existing door frame must
be removed along with all of the existing fluorescent
components in the fixture. A hinge rail is inserted
between the ceiling grid and fixture housing at each
end. The hinge tabs on the retrofit insert are
engaged with the slots in the hinge rails. With the
insert hanging open the electrical connection can be
made and ground strap installed. The final step is to
close the new LED door secure the latches.
Features
High Performance, Architecturally Styled
Provides Soft, Even Illumination
Long-life, efficient LED engine
Available as either a new fixture or as a one-piece retrofit insert
Retrofit option installs very easily in most parabolic and prismatic
troffers
Highlights
3.50
"
3.75
"
Installation
Retrofit
New Fixture
23.75
Listed
L17
