Eco-Brite
High Bay Industrial Luminaire
Photometrics
Ordering Information
Size
F-14EC - 1' x 4'
Part Number = Fixture Size + Reflector Material + # Lamps + Lamp Wattage + Voltage + Ballast Type + Options
(Example F-14ECEA632277H = 1'x4' Eco-Brite High Bay with an 95% aluminum reflector, 6-32W lamps, 277 volts high lumen ballasts)
* 8L available in T5 only
Reflector
EA - 95%Enhanced Alum
WR - 92% White Enamel
# Lamps
3
4
5
6
8*
Lamp Watts
32
54
Voltage
UNV
Options
H - High Ballast Factor
N - Normal Ballast Factor
FL - Flange Mounting Kit
Y- Y-Fit Hanger Kit
U - Uplight Notching
WG - Wire Guard
(888) 308-9197
Series
Energy Solutions International
.ENERGY SOLUTIONS 1 X 4 FLUORESCENT LUMINAIRE
WITH WHITE INTERIOR, SPECULAR REFLECTOR AND NO LENS
SIXT8 LINEAR FLUORESCENT 32 WATT LAMPS, LUMEN RATING 2900 LMS. TWO SYLVANIA QT332PLUS
BALLASTS OPERATING AT 277 VAC AND 226 WATTS
16.00
1.37
CANDLEPOWER SUMMARY
ZONAL LUMENS AND PERCENTAGES
** EFFICIENCY = 90.9% **
PAINT REFLECTANCE = 0.78 S/MH = 1.17
SC (ALONG) = 1.17 SC (ACROSS) = 1.06
PREPARED IN PHOTOPIA FOR
ENERGY SOLUTIONS
ST. PAUL, MN
LUMINANCE SUMMARY - CD./SQ.M.
