VA
Vapor Proof Fixture - Standard Width
Installation
Technical Data
Housing: Fiberglass composite that will with-
stand extreme temperatures. Manufactured with
sufficient knock-outs for wiring.
Lens: Impact resistant lens.
Reflector: Can be ordered with a 95% specular
or a 92% diffuse white enamel. Substrate is high
quality aluminum. The reflector profile is opti-
mized using computer analysis and manufactured
using state of the art CNC equipment. A protec-
tive premask is applied to all reflective surfaces
prior to manufacture.
Construction: The solid body provides exception-
al rigidity. The reflectors are attached to the fixture
body with a quarter-turn fastening system. No
tools or additional fasteners are required for reflec-
tor installation / removal. The lens is secured to
the fixture body with a compression fit.
Features
High-performance vapor proof luminaire available in T8
and T5.
Energy efficient alternative to HID systems
Instant-on, step-dimming ready
Available on-board occupancy sensor
Meets or Exceeds
1598 Standard
Series
Energy Solutions International
Ordering Information
Size
F-12VA - 1' x 2'
F-14VA - 1' x 4'
F-18VA - 1' x 8'
Part Number = Fixture Size + Reflector Material + # Lamps + Lamp Wattage + Voltage + Ballast Type + Options
(Example 18VAEA632277H = 1'x8' Vapor Power Strip with an enhanced aluminum reflector, 6-32W lamps, 277 volts, and a high power ballast)
Reflector
EA - Enhanced Alum
WR - White Enamel
BC - Ballast Cover
# Lamps
1
2
3
4
6
Lamp Watts
32
Voltage
UNV
Ballast
N - Normal
H - High Ballast Factor
L - Low Ballast Factor
54
6.00
100.00
6.75
I33
