EX
High Performance Luminaire
Photometric Summary Charts
(888) 308-9197
Series
Energy Solutions International
Ordering Information
Size
F-14EX - 1' x 4'
F-24EX - 2' x 4'
F-24EX - 3' x 4'
Part Number = Fixture Size + Reflector Material + # Lamps + Lamp Wattage + Voltage + Ballast Type + Options
(Example F-24EXEA632UNVH-UL = 2'x4' EX Series with an enhanced alum. refl, 6-32W lamps, and an HP universal voltage ballast and uplight)
* Fixtures supplied with Normal Beam unless specified otherwise;
fixtures can be field modified for various beam spreads
Reflector
EA - Enhanced Alum
AA - Anodized Alum
WR - White Enamel
# Lamps
2-12
Lamp Watts
32
54
Voltage
UNV
480
Ballast Type
N - Normal
H - High Ballast Factor
L - Low Ballast Factor
Options
DV - Dust Venting
UL - Uplight
P1* - Task Beam
P2* - Normal Beam
P3* - Wide Beam
OBS - On-board Sensor
S/C
Eff.
S/C
Eff.
P1 0.66
93.7
P1 0.51
95.4
P2 0.88
93.5
P2 0.73
95.3
P3 1.25
93.1
P3 1.17
95.1
S/C
Eff.
S/C
Eff.
P1 0.85
89.2
P1 0.55
93.7
P2 1.06
87.7
P2 0.8
93.3
P3 1.28
85.1
P3 1.15
94.5
S/C
Eff.
S/C
Eff.
P1 0.71
92.2
P1 0.54
94.6
P2 0.92
92
P2 0.77
94.6
P3 1.26
91.7
P3 1.15
94.5
S/C
Eff.
S/C
Eff.
P1 1.13
88.3
P1 0.78
93.1
P2 1.29
87.1
P2 1.21
92.7
P3 1.5
85.1
P3 1.6
92
F-24EXEA832
F-24EXEA854
F-14EXEA654
F-14EXEA632
F-14EXEA432
F-14EXEA454
F-24EXEA632
F-24EXEA654
Optional "Dust Vents" create airflow around lamps to
minimize accumulation
Optional uplight notching available
S/C
Eff.
S/C
Eff.
P1 1.12
88.3
P1 0.93
93.1
P2 1.32
87.1
P2 1.24
92.5
P3 1.54
85.1
P3 1.57
92.1
F-34EXEA1232
F-34EXEA1254
Options Cont.
L - Lens
WG - Wire Guard
