steel. Provided as a three-piece break-apart
set to simplify material handling. Prepunched
for lampholders and alignment holes.
a 95% reflective specular finish or a 92%
reflective white enamel coating. The reflector
substrate is 0.020" high quality aluminum.
The reflector profile is optimized using com-
puter analysis and manufactured using state
of the art CNC equipment. A protective pre-
mask is applied to all reflective surfaces prior
to manufacture.
all the materials necessary to retrofit one fixture. This
includes an energy efficient electronic ballast, twist-lock
lampholders, a 2008 code required electrical disconnect,
and all required hardware for installation. Providing that
the existing ballast covers are four feet long, they can be
reused with the kit or optional reflectors can be added
when purchasing the RetroPAK.
socket bars are removed. With the new ballast installed, the ESI
socket bars are attached to the existing channel with self-tapping
screws. The ESI socket bars are folded around the channel as
shown in the diagram to the right. If reusing the existing ballast
covers, self-tapping screws may be required for attachment to the
new socket bars. The optional reflectors are attached with provided
quarter-turn fasteners.
optimal performance
simplifies and speeds up
installation
disconnect included
95% to meet every performance and budget
requirement.
