Features
Provides soft even illumination
Long life
k Hrs+
Available in x , x and x configurations
Made in the USA
Retrofit Kit replaces the ESI PG, PK and VA Series
Available in ,
, ,
and ,
Lumen Packages
Ordering Information
Style
F - Fixture
K - Retrofit Kit
Size
12VA - 1' x 2'
14VA - 1' x 4'
18VA - 1' x 8'
Output
30 - LED 30K Color Temp
35 - LED 35K Color Temp
40 - LED 40K Color Temp
50 - LED 50K Color Temp
Lens
Options
FR - Frosted Deep Lens
FD - Frosted Ribbed Lens
SS - Stainless Steel Latches
PC - Poly Carb Latches
Light Engine
VA Series
Vapor Tight Luminaire
Part Number = Style + Size + Light Engine + Output + Lens + Options
(Example F-14VA-P4H-SS-FD = 1'X4' VA Series with a 4' PrevaLED
system stainless steel latches and a frosted deep lens)
Technical Data
.
x
.
x
.
x
.
x
P2N - LED 54 Watt
P4L - LED 25 Watt
P4N - LED 30 Watt
P4H - LED 40 Watt
P8N - LED 60 Watt
P8H - LED 80 Watt
Housing: 5VA rated fiberglass composite housing
Lens: 100% virgin impact resistant acrylic. Available
in polycarbonate for high abuse environments or
with a DR blend for maximum chemical resistance
Construction: Electrical components are mounted
to an integrally hinged gear tray. No tools are
required for ballast access. Captive stainless steel
latches secure the lens.
Mounting:Optional stainless hanging straps allow
easy fixture installation without drilling through the
enclosure.
4.00"
6.750
