Installation
1x4 - 16.00" Wide
2x4 - 20.00" Wide
3x4 - 28.50" Wide
3.75
" (All)
48.00
"
(T8) / 46.00" (T5)
Quality, cam-lock
lampholders
Tool-free quarter-turn
ballast access
Computer designed, CNC formed
0.020" specular aluminum reflector
Technical Data
Ballast Channel: 20ga. (0.032") pre-painted
steel die formed with sufficient knockouts for
electrical supply.
Finish: All cold rolled steel parts are painted with
a smooth, glossy, highly reflective white paint.
Reflector: Can be ordered with a 95% specular,
a 85% specular, or a 92% diffuse white enamel.
(For maximum performance, 95% specular is rec-
ommended.) Substrate is 0.020" high quality alu-
minum. The reflector profile is optimized using
computer analysis and manufactured using state
of the art CNC equipment. A protective premask
is applied to all reflective surfaces prior to manu-
facture.
Construction: The solid reflector body provides
added rigidity. The reflectors are attached to the
endplates with screws.
Mounting: Fixture is designed for chain or
Gripple installations.
Features
A Breakthrough Alternative to HID
High-Bay Systems
Superior Light Quality and Efficiency
Tool-free maintenance
Isolated ballast chamber
Optimally designed for heat dissipation
Highlights
EX
High Performance Luminaire
Meets or Exceeds
1598 Standard
Series
Energy Solutions International
I5
