AR
Asymmetric Recessed Wallwash Fixture
Photometrics
Ordering Information
Size
F-12AR - 1' x 2'
F-14AR - 1' x 4'
Part Number = Fixture Size + Reflector Material + # Lamps + Lamp Wattage + Voltage + Ballast Type + Options
(Example F-14AREA132277 = 1'x4' Asymmetric Recessed Fixture with an enhanced alum. reflector, 1-32W lamps, and 277 volts)
Reflector
EA - Enhanced Alum
AA - Anodized Alum
WR - White Enamel
# Lamps
1
2
Lamp Watts
17
32
Voltage
120
277
Ballast
N - Normal
H - High Ballast Factor
L - Low Ballast Factor
(888) 308-9197
Series
Energy Solutions International
.ENERGY SOLUTIONS 1 X 4 FLUORESCENT LUMINAIRE
WITH WHITE INTERIOR, SPECULAR REFLECTOR AND NO LENS
ONE T8 LINEAR FLUORESCENT 32 WATT LAMPS, LUMEN RATING 2950 LMS.
ONE SYLVANIA QT132277 BALLAST OPERATING AT 277 VAC AND 29 WATTS
12.00
4.12
CANDLEPOWER SUMMARY
ZONAL LUMENS AND PERCENTAGES
** EFFICIENCY = 85.0% **
PAINT REFLECTANCE = 0.78 S/MH = 3.46
SC (ALONG) = 1.02 SC (ACROSS) = 3.46
PREPARED IN PHOTOPIA FOR
ENERGY SOLUTIONS
ST. PAUL, MN
LUMINANCE SUMMARY - CD./SQ.M.
