WS
Wide Spread Industrial Strip Fixture
Photometrics
Ordering Information
Size
F-14WS - 1' x 4'
Part Number = Fixture Size + Reflector Material + # Lamps + Lamp Wattage + Voltage + Ballast Type + Options
(Example F-18WSEA432277H = 1'x8' Wide Spread Strip with an enhanced aluminum reflector, 4-32W lamps, 277 volts, and a high power ballast)
Reflector
EA - Enhanced Alum
AA - Anodized Alum
WR - White Enamel
TE - 0.032 Enhanced
# Lamps
2
F-18WS - 1' x 8'
4
Lamp Watts
32
Voltage
UNV
Ballast
N - Normal
H - High Ballast Factor
L - Low Ballast Factor
Options
WG - Wire Guard
(888) 308-9197
Series
Energy Solutions International
11.00
0.875
ZONAL LUMENS AND PERCENTAGES
** EFFICIENCY = 93.2% **
PAINT REFLECTANCE = 0.78 S/MH = 2.63
SC (ALONG) = 1.40 SC (ACROSS) = 2.63
PREPARED IN PHOTOPIA FOR
ENERGY SOLUTIONS
ST. PAUL, MN
LUMINANCE SUMMARY - CD./SQ.M.
ENERGY SOLUTIONS 1 X 8 FLUORESCENT LUMINAIRE
WITH WHITE INTERIOR, SPECULAR REFLECTOR AND NO LENS
FOUR T8 LINEAR FLUORESCENT 32 WATT LAMPS, LUMEN RATING 2750 LMS.
ONE SYLVANIA QT4X32/277 BALLASTS OPERATING AT 277 VAC
