and Value-added Technology
steel. Prepunched for lampholders and wire
passageway. Tabs on socket bars securely
mount the reflector in the correct position
relative to the lamps. Note: ESI's optional
uni-bracket is pictured in the diagrams.
85% reflective anodized finish, a 95% reflective
enhanced or film finish, or a 92% reflective white
enamel. The substrate is 0.020" high quality alu-
minum. The reflector profile is optimized using
computer analysis and manufactured using state
of the art CNC equipment. A protective premask
is applied to all reflective surfaces prior to manu-
facture.
last and socket bars are removed. With the new ballast
and optional accessories installed, the ESI socket bars
are attached to the existing channel with self-tapping
screws. The reflector is positioned between the socket
bars and attached with quarter-turn fasteners.
Luminaire Disconnects and Accessories
Configurations
Removal
