EC
LED Elevator Cove Kit
Watts Per Foot
Dimensions
Features
Meets or Exceeds
1598 Standard
*LED Pending
Series
Energy Solutions International
Ordering Information
Style
K - Retrofit Kit
Part Number = Fixture Style + Fixture Size + Output + Voltage + Options
(K-8-EC-40-CV-PA = 8' Elevator Cove Retrofit Kit with 40K Color Temperature, Constant Voltage that is Pre Assembled)
Size
Output
Voltage
Options
Consult Factory for additional Accessories
48.00"
3.50"
3.50"
2.35""
3 - 31EC - 3' - 31'
30 - 30K Color Temperature
35 - 35K Color Temperature
40 - 40K Color Temperature
50 - 50K Color Temperature
CV - Constant Voltage
PA - Pre Assembled
3 Feet = 4.62W
8 Feet = 12.32W
15 Feet = 23.10W
16 Feet = 24.64W
19 Feet = 29.26W
20 Feet = 30.80W
24 Feet = 36.96W
26 Feet = 40.04W
27 Feet = 41.58W
31 Feet = 47.74W
Constant voltage power supply allows long runs with a single driver
Kit designed for easy mounting on industry standard strip bodies
All aluminum construction offers superior heat dissipation
for long component life
Diffuse acrylic lens eliminates pixelation
Proprietary reflector angles maximize cove efficiency
L18
