LED Vapor-tight Luminaire
Features
Soft, even illumination
Long life (50K hrs+)
60-70% Energy Savings over traditional systems
Available in a 1x2 and 1x4 configuration
Made in the USA
Series
Energy Solutions International
(888) 308-9197
Ordering Information
Part Number = Fixture Series + Light Engine + Lamp Color + Voltage
(Example L-12VABC30CC50-PC - 1x2 LED VA Series, 30W, 50K, Polycarb Lens)
Series
L-12VA - 1'x2'
L-14VA - 1'x4'
VA
Certification Pending
Technical Data
LED Light Engine
Housing: 5 VA rated fiberglass composite
housing
Lens: 100% Virgin Impact Resistant Acrylic.
Available in polycarbonate for high abuse envi-
ronments or with a DR blend for maximum
chemical resistance.
Construction: Electrical components are mounted to an
integrally hinged gear tray. No tools are required for ballast
access. Captive stainless steel latches secure the lens.
Mounting: Optional stainless hanging straps allow easy fix-
ture installation without drilling through the enclosure.
51.750"(1x4)
27.875 (1x2)
Reflector
EA - Enhanced Alum
AA - Anodized Alum
WR - White Enamel
BC - Ballast Cover
Options
SS - Stainless Latches
HGR - Stainless Hanger
PC - Polycarb Lens
Light Engine
20CC -20W Constant Current (1500 - 1700 Lumens)
Color
35 - 3500K
40 - 4000K
50 - 5000K
30CC - 30W Constant Current (2150 - 2600 Lumens)
35CC - 35W Constant Current (2900 - 3350 Lumens)
50CC -50W Constant Current (4300 - 4800 Lumens)*
*available in 1x4 only
Output: Values in table below are for the lightstrip only. System
lumen totals are pending photometric testing
Light Engine: High quality
Nichia emitters are secured to
patented flexible substrate,
providing optimal thermal
transfer and system reliability.
L14
