Dimensions
Features
lumens, custom sizes available
Adjustable aim allows for various distribution patterns
Diffusing lens options available to minimize pixelation and glare
Optional motion control
Ordering Information
Style
F - Fixture
Size
22VH - 2' x 2'
23VH - 2' x 3'
Output
50 - LED 50K Color Temp
Lens
Blank - Clear Lens
DL - Diffusing Lens
Options
OBS - On Board Sensor
D - Dimming
Y - Y Toggle Hangers
Light Engine
P2H - 2' LED 105W
P3H - 3' LED 150W
Mounting: Fixture is designed for chain
or aircraft cable hanging. Consult factory
for mounting accessories.
Construction: Very robust all aluminum
chassis and components allows for maximum
dissipation of heat and long life of electrical
components.
Light Engine: OSRAM PrevaLED Modules
Power Supply: OSRAM OPTOTRONIC
Optical:
Aluminum reflector design fully
optimized using computer analysis and
manufactured using state of the art
CNC equipment.
VH Series
Variable Distribution Luminaire
P1 Aisle
P2 High Bay
P3 Low Bay
Aisle Setting:
Spacing Criteria - 0.74 (Narrow)
Highbay Setting: Spacing Criteria - 1.18 (Medium)
Lowbay Setting Spacing Criteria - 1.64 (Wide)
2.75"
17.00"
24.00", 36.00"
17.00"
Part Number = Style + Size + Light Engine + Output + Lens + Options
(Example F-22VH-P2H-50-DL-OBS-Y = 2'X2' Variable Distribution Fixture with
105W 50K LED Light Engine, Diffusing Lens On-Board Sensor and Y-Toggles)
L16
