CP
Cove Perfected T5 Fixture
Technical Data
Meets or Exceeds
1598 Standard
Series
Energy Solutions International
2.63" 3.00"
5.63"
1X2
1X3
1X4
1X6
1X8
22.4"
34.3"
46.0"
68.6"
94.0"
Photometrics
Ordering
Part Number = Size + Style + Profile + Material + Ballast
(Example F-14CP8NAH = 1'x4' Cove Strip without an optional reflector insert and an HP ballast)
Size
F-12CP5 - 1' x 2'
F-13CP5 - 1' x 3'
F-14CP5 - 1' x 4'
F-16CP5 - 1' x 6'
F-18CP5 - 1' x 8'
Reflector Insert
EA - 95% Enhanced
MM - 95% Diff. Alum.
WO - 98% White Optic
NA - Without Optional Insert
Ballast
N - Normal
H - High (HO)
(888) 308-9197
Photometric
files available by
request
Efficiency:
83.8%
(Shield fully retracted)
Features
· Three Mounting Positions Allow For Three Distributions: 110 deg., 120 deg. or 130 deg.
· 2.63" Height Allows For Easy Concealment
· Designed For Easy End-To-End Row Mounting.
· Adjustable Backlight Shield With Serrated Edge Allows Backlight To Be Precisely
Controlled With a Soft, Room Side Appearance.
· Can Be Mounted 18", Or Less, From Ceiling Surface.
· Smooth Ceiling Illumination Without Typical Hot Spots.
· No Socket Shadow.
· Aluminum construction standard.
· Brand Name Ballasts: Normal and High (HO) ballasts available.
· Combine with Matching Lamps for extended Lamp/Ballast Warranty.
· Reflectors offer up to 98% reflective materials.
· Can be customized for specific applications,
· Proudly Made in West St. Paul, Minnesota, USA!
-10 Degree
Mounting
0 Degree
Mounting
+10 Degree
Mounting
A2
