LG
Lay-in Guarded High Bay
Photometrics (shown with 6L T8)
(888) 308-9197
Series
Energy Solutions International
.ENERGY SOLUTIONS 2 X 4 FLUORESCENT LUMINAIRE
WITH SPECULAR REFLECTOR AND WIRE GUARD
SIX T8 LINEAR FLUORESCENT 32 WATT LAMPS, LUMEN RATING 3000 LMS.
TWO SYLVANIA QTP3X32T8 BALLASTS OPERATING AT 277 VAC AND 224 WATTS
20.75
2.43
CANDLEPOWER SUMMARY
ZONAL LUMENS AND PERCENTAGES
** EFFICIENCY = 85.0% **
PAINT REFLECTANCE = 0.78 S/MH = 1.15
SC (ALONG) = 1.26 SC (ACROSS) = 1.15
PREPARED IN PHOTOPIA FOR
ENERGY SOLUTIONS
ST. PAUL, MN
LUMINANCE SUMMARY - CD./SQ.M.
Ordering Information
Size
F-24LG - 2' x 4'
Part Number = Fixture Size + Reflector Material + # Lamps + Lamp Wattage + Voltage + Ballast Type + Options
(Example F-24LGEA632UNVH-WG = 2'x4' LG Series with an enhanced alum. refl, 6-32W lamps, a universal voltage HP ballast and wire guard)
Reflector
EA - Enhanced Alum
AA - Anodized Alum
WR - White Enamel
# Lamps
4
6
8
Lamp Watts
32
54
Voltage
UNV
480
Options
WG - Wire Guard
CL - Clear Lexan Lens Insert
850 - 850 Series Lamps
