e
EC
Economy High Bay Industrial Luminaire
Meets or Exceeds
1598 Standard
Series
Energy Solutions International
Installation
16.000
"
3.625
"
48.000
"
Quality, cam-lock
lampholders
Solid, 0.028" steel body provides
rigidity and durability
CEE Rated Electronic ballasts
available in both standard and high
lumen versions
Swing-down reflector
assembly
850 series lamps installed
Computer designed, CNC formed
0.016" aluminum reflector
Technical Data
Housing: 22ga. (0.028") pre-painted steel die
formed with sufficient knockouts for mounting and
electrical supply.
Finish: All cold rolled steel parts are post-painted
with a smooth, glossy, highly reflective white
paint.
Reflector: Substrate is 0.016" high quality alu-
minum. The reflector profile is optimized using
computer analysis and manufactured using state
of the art CNC equipment. A protective premask
is applied to all reflective surfaces prior to manu-
facture.
Construction: The solid fourteen-bend body pro-
vides added rigidity. The socket bars are securely
bolted to the fixture body. The reflector attaches
with quarter-turn fasteners. No tools are required for
reflector installation and removal.
Mounting: Fixture is designed for surface or sus-
pended applications
Features
A Breakthrough Alternative to HID
High-Bay Systems
Optimized to Deliver Good Performance and Low
Cost
Powered by Brand Name Ballasts and Lamps
Stock Program for Fast Delivery
CEE Rated Components
Highlights
I30
