LX
Direct-Indirect LED Troffer Luminaire and Kit
Ordering Information
Style
K- Retrofit kit
F- New Fixture
Part Number = Style + Size + Light Engine + Color + Lens + Options
(Example F-24LX-L4N-41-CM = 2'x4' LX Series Fixture with a 35W LED light engine and a ribbed lens with liner)
Size
22LX - 2'x2'
14LX - 1'x4'
24LX - 2'x4'
Color
35 - 35K
41 - 41K
50 - 50K
Lens
CM- Linear Ribbed with Liner
Options
P
DF - Door Frame Kit
A - Pre-assembled Kit
(888) 308-9197
Series
Energy Solutions International
Photometrics
Standard Configurations
Light Engine
L2L - 2' LED
L2N - 2' LED
L2H - 2' LED
L2V - 2' LED
L4L - 4' LED
L4N - 4' LED
L4H - 4' LED
L4V - 4' LED
*60,000+ HRS L70 FOR 53W 2X4
(L)ow
(N)ormal
(High
(V)ery High
1x4
Watts Lumens
12
16
22
39
830
1295
1925
3360
Current Replaces
450
700
1040
1820
1L T8 Continuous
1L T8
2L T8
3L T8
(L)ow
(N)ormal
(High
(V)ery High
2x2
Watts Lumens
12
16
22
30
830
1295
1925
2590
Current Replaces
450
700
1040
1400
Low Light Level
2L T8 FO17
2L Ubend 6"
3L Ubend 2.875"
(L)ow
(N)ormal
(High
(V)ery High
2x4
Watts Lumens
22
39
44
53
2590
3360
3700
4625
Current Replaces
1400
1820
2000
2500
Low Light Level
2L T8
2L T8+
3L/4L T8
*
2x2 door frame kit replaces 22.5" x 22.5" prismatic lens
2x4 Door frame kit replaces 22.75" x 46.75" prismatic lens
