Premium Prismatic and
Secondary Proprietary Optics
Thermally Managed Light Engine
Technical Data
Housing: 20ga. (0.032") pre-painted steel die
formed with sufficient knockouts for electrical sup-
ply.
Finish: All cold rolled steel parts are painted with
a smooth, glossy, highly reflective white paint.
Optics: 22" premium acrylic open prismatic
refractor combined with diffusing blasted dome
and uplight uplight ring (optional).
Heat Sink: Extruded aluminum and machined
aluminum heat sink combination custom engi-
neered for optimal thermal integrity.
LED Module: Patented 136 LED array Highbay
module using high brightness LED and patented
metal core board design protected by
Thermadjust
TM
technology for extra long life and
peak performance.
Mounting: Fixture is designed for hook and eye
installations. Consult factory for more options.
Features
Superior Thermal Management
Patented LED Protection Circuitry
Soft Appearance Beats Competition
Available Up to 11,700 Lumens
DLC Compliant
Dimmable
Highlights
HB
LED Retail High Bay
Series
Energy Solutions International
30"
Dimmable LED Driver
L5
