Plasma Shoebox Fixture
Technical Data
Standard Configurations
Features
Meets or Exceeds
1598 Standard
*LED Pending
Energy Solutions International
Ordering Information
Mounting: Options for pole
or wall mounting available.
Consult factory.
Construction: Very robust
all aluminum chassis and
components allows for
maximum dissipation of
heat and long life of
electrical components.
Light Engine: Electrode
free Metal Halide,
electronic power supply
and RF generator.
Optical: Proprietary 95%
Enhanced Aluminum
reflector design fully
optimized using computer
analysis and manufactured
using state of the art CNC
equipment.
Consult Factory for additional Accessories
Style
F - Fixture
Enclosure
SB - Shoebox
HID Equivalent
250 - 250 Watts
400 - 400 Watts
1000 - 1000 Watts
Distribution
III - Profile 3
IV - Profile 4
V - Profile 5
Voltage
UNV - Universal
480 - 480 Volt
Options
PC - Photo Cell Sensor
D - Dimming
Light Engine
EH - Electrode Free HID
Part Number = Enclosure + Light Engine + HID Equivalent + Distribution + Voltage + Options
(Example F-SBEH250UNV-III-PC = Shoebox electrode free HID, 250 watts,universal voltage with a profile 3 reflector and a
photo cell sensor)
ES
Series
70+ CRI
Distributions Types III, IV and V available
20-100% Continuous Dimming
50,000 Hour Lamp Life
Uniform light distribution and excellent control
Watts
Fixture
EH250
135W
10,000 250W HID
400W HID
1000W HID
235W
23,000
470W
44,200
EH400
EH1000
Lumens Replaces
L19
