Installation
Technical Data
A low-profiled, easy to install solution for
most pin-based CFL recessed fixtures utilizing
LED PAR lamp light sources with a standard
eddison screw in base.
Socket: One-piece E-26, medium base
phenolic sockets. Rust- resistant spring steel clip.
Standard leadsare No. 18 AWG 105 C AWM-TEW
plastic insulated wire, 6" long, stripped 3/4".
20 gauge steel
660 Watts/ 250Vac
Concealed wire connections
bypass existing ballasts
Features
Converts existing recessed CFL Can Light
Into High performance LED Down Light
Provides Energy Saving, Long Life Alternative to
Existing CFL Can Light
Fits Most modern recessed CFL Cans and accepts
Screw In LED PAR Lamps
LD
LD Series LED PAR Can Retrofit Kit
Series
Energy Solutions International
3.00
2.00
2.06
2.19
1.44
2.06
Ordering Information
Ordering Information
Series
K-LD
Part Number = Series + Wattage + Lamp Color + Options
(Example K-LD-21-830PA = LD Kit with a 21 watt LED PAR lamp, 830 Lampcolor temperature, pre assembled)
Wattage
21- 21 Watts
Color
830 - 3000K
841 - 4100K
850- 5100K
Options
PW- Pre Wired
PA- Pre Assembled
K16
