VS
Vapor Proof Fixture - Narrow Width
Installation
Technical Data
Housing: 5 VA rated fiberglass composite that
will withstand extreme temperatures.
Manufactured with sufficient knock-outs for wir-
ing.
Lens: Impact resistant polycarbonate lens.
Reflector: Can be ordered with a 95% specular
or a 92% diffuse white enamel. Substrate is high
quality aluminum. The reflector profile is opti-
mized using computer analysis and manufactured
using state of the art CNC equipment. A protec-
tive premask is applied to all reflective surfaces
prior to manufacture.
Construction: The solid body provides exception-
al rigidity. The reflectors are attached to the fixture
body with a quarter-turn fastening system. No
tools or additional fasteners are required for reflec-
tor installation / removal. The lens is secured to
the fixture body with a compression fit.
Features
High-performance Vapor Proof Luminaire Available in T8
and T5 (dimming options available).
Features Impact Resistant Polycarbonate Lens (1x4)
Available with Stainless Steel Hanging Kit and Stainless
Steel Latches
Fiberglass Composite Body that is 5 VA Rated. Tested to
withstand extreme temperatures
Meets or Exceeds
1598 Standard
Series
Energy Solutions International
Ordering Information
Size
F-12VS - 1' x 2'
F-14VS - 1' x 4'
Part Number = Fixture Size + Reflector Material + # Lamps + Lamp Wattage + Voltage + Ballast Type + Options
(Example F-14VSEA132UNVH = 1'x4' Vapor Slim with an enhanced aluminum reflector, 1-32W lamps, universal voltage high power ballast)
Reflector
EA - Enhanced Alum
WR - White Enamel
BC - Ballast Cover
# Lamps
1
Lamp Watts
17
Voltage
UNV
Ballast
N - Normal
H - High Ballast Factor
L - Low Ballast Factor
D - Dimming Ballast
Options
SS - Stainless Latches
HGR - Stainless Hanger
32
54
3.500
4.250
51.750
I32
