Thermally Managed Light Engine
Technical Data
Housing: Heavy Duty Die Cast Aluminum
Housing. Dark Architectural Bronze Powder-coat
Finish, Hinged Front Frame, Silicon rubber gasket
to prevent leakage, ½" tapped holes available for
installing photocell (photocell by others)
Lens: Heat & Impact Resistant Borosilicate Lens
LED Module: Patented module using high bright-
ness LED and patented metal core board design
protected by Thermadjust
TM
technology for extra
long life and peak performance.
Mounting: Cast-in template for mounting directly
over a 4" recessed outlet box or use surface con-
duit
Features
Superior Thermal Management
Patented LED Protection Circuitry
Available Up to 3780 Lumens
IP65 Certified
Highlights
WP
LED Wallpack
Series
Energy Solutions International
12VDC Constant Voltage
LED Driver
LISTED
Certified
L10
