VA
LED T8HO Vapor Tight Fixture & Retrofit Kit
Installation
Technical Data
Housing: Fiberglass composite that will with-
stand extreme temperatures. Manufactured with
sufficient knock-outs for wiring.
Lens
Lamps: LED T8HO long life lamps.
: Impact resistant lens.
Reflector: Can be ordered with a 95% specular
or a 92% diffuse white enamel. Substrate is high
quality aluminum. The reflector profile is opti-
mized using computer analysis and manufactured
using state of the art CNC equipment. A protec-
tive premask is applied to all reflective surfaces
prior to manufacture.
Construction: The solid body provides exception-
al rigidity. The reflectors are attached to the fixture
body with a quarter-turn fastening system. No
tools or additional fasteners are required for reflec-
tor installation / removal. The lens is secured to
the fixture body with a compression fit.
Features
Long life, Sylvania LED T8HO Lamps
Energy efficient alternative to fluorescent systems
0-10 Volt dimming available
Available on-board occupancy sensor
Durable construction, Stainless steel latches
Series
Energy Solutions International
Ordering Information
Style
12VA - 1' x 2'
1 - 1 Lamp
2 - 2 Lamps
4 - 4 Lamps
35 - LED 3500K Color Temp
41 - LED 4100K Color Temp
50 - LED 5000K Color Temp
14VA - 1' x 4'
18VA - 1' x 8'
K - Retrofit Kit
F - New Fixture
Part Number = Fixture Size + Reflector Material + # Lamps + Lamp Wattage + Voltage + Ballast Type + Options
(Example 18VAEA632277H = 1'x8' Vapor Power Strip with an enhanced aluminum reflector, 6-32W lamps, 277 volts, and a high power ballast)
Size
EA - Enhanced Aluminum
WR - White Reflective
BC - Ballast Cover
Reflector
# of Lamps
Output
Options
D - Dimming (0-10V)
PC - Poly Carb. Latches
SS - Stainless Steel Latches
6.00
100.00
6.75
L22
