KS
Strip Fixture Retrofit Kit
Photometrics
*shown for an enhanced aluminum reflector, full reports for all products available upon request
Summaries
95% reflective, specular enhanced aluminum
Efficiency:
95.1%
Spacing height ratio (along) :
1.26
Spacing height ratio (across) :
1.25
Photometric data file:
18STEA8S232.ies
85% reflective, specular anodized aluminum
Efficiency:
91.1%
Spacing height ratio (along) :
1.35
Spacing height ratio (across) :
1.38
Photometric data file:
18STAA8S232.ies
92% reflective, diffuse white enamel
Efficiency:
91.4%
Spacing height ratio (along) :
1.30
Spacing height ratio (across) :
1.37
Photometric data file:
18STWR8S232.ies
(888) 308-9197
Series
Energy Solutions International
Ordering Information
Size
K-14 - 1' x 4' Kit
K-18 - 1' x 8' Kit
Part Number = Fixture Size + Reflector Material + # Lamps + Channel Width + Options
(Example K-18WR8S432-VER-BJB = 1'x8' Kit,white 8S Refl., 4-32W lamps, to fit a 4.25" or 5.00" channel, including Tw)
* Not available with 6" or 8" Blank Size
** Not available with 6" Blank Size
Reflector
EA - Enhanced Alum
# Lamps
1
2
3
4
6
Wattage
32
54
AA - Anodized Alum
WR - White Enamel
WS - White Steel
Blank Size
6 - 6" Blank
BC - Ballast Cover Only
8 - 8" Blank
12 - 12" Blank
Distribution
S - Standard
F - Focused*
W - Wide**
Width
4.25"
4.50"
4.75"
5.00"
VER - 4.25-5.00"
Options
PW - Pre-wired
UNV - Unv Ballast
841 - 841 Lamps
850 - 850 Lamps
A - Hardware Pack
