LH
LED High Bay Luminaire
Series
Energy Solutions International
16.00
"
48.00
"
6.00
"
Technical Data
Light Engine: High quality
Nichia emitters are secured to
patented flexible substrate,
providing optimal thermal
transfer and system reliability.
Mounting: Fixture is designed for chain or
Gripple installations.
Features
LED engines are field adjustable to allow various
distribution patterns
Available in 2x2 and 2x4 configurations
Optional motion control
System output of up to 22,000 lumens
Ordering Information
Part Number = Fixture Size + Light Engine + Output + Color + Options
(Example L-24LH-M3N-50 = 2'x4' LED High Bay, 3 Module Normal Output (135W, 14,400 Board Lumens), 5000K)
Installation
Top View
End View
Size
L-24LH - 2'x4' LED High Bay
Output
L - Low
Color
Options
41 - 4100K
OBS - Sensor
System wattage and board lumens are subject to change
Light Engine
M2 - Two Modules
M3 - Three Modules
M4 - Four Modules
H - High
N - Normal
50 - 5000K
WG - Bolt-on Wire Guard
CL - Clear Lens Kit
L6
