Energy Solutions International
Meets or Exceeds 1598 Standard
Ordering Information
Size
F-14LI - 1' x 4'
F-18LI - 1' x 8'
Part Number = Fixture Size + Reflector Material + # Lamps + Lamp Wattage + Voltage + Ballast Type + Options
(Example F-14LIEA232UNVH-AH-SC = 1'x4' LI Series with a 95% alum. refl., 2-32W lamps, univ. HP ballast, alum. housing and sealed lens.)
Reflector
EA - 95%Enhanced Alum
AA - 85% Anodized Alum
WR - 92% White Enamel
# Lamps
2
4
Lamp Watts
32
54
Voltage
UNV
480
Options
AH - Aluminum Housing
SC - Sealed Clear Lens
HUB - Hanging Hub
YTOG - T-Toggle Hangers
V - V-hangers
Photometrics
.ENERGY SOLUTIONS 1 X 8 FLUORESCENT LUMINAIRE
WITH WHITE INTERIOR, SPECULAR REFLECTOR AND CLEAR LENS
FOUR T8 LINEAR FLUORESCENT 32 WATT LAMPS, LUMEN RATING 2900 LMS. ONE SYLVANIA
QT432PLUS BALLASTS OPERATING AT 277 VAC AND 156WATTS
7.62
2.00
CANDLEPOWER SUMMARY
ZONAL LUMENS AND PERCENTAGES
** EFFICIENCY = 87.5% **
PAINT REFLECTANCE = 0.78 S/MH = 0.87
SC (ALONG) = 1.30 SC (ACROSS) = 0.87
PREPARED IN PHOTOPIA FOR
ENERGY SOLUTIONS
ST. PAUL, MN
LUMINANCE SUMMARY - CD./SQ.M.
