Retrofit
Direct / Indirect T8 Troffer Retrofit Kit
Ordering Information
(888) 308-9197
Series
Energy Solutions International
Size
K-22DI - 2' x 2'
K-24DI - 2' x 4'
Part Number = Fixture Size + Reflector Material + # Lamps + Lamp Wattage + Options
(Example K-24DIWR232 = 2'x4' Direct/Indirect Retrofit Kit with a white aluminum reflector for 2-32W lamps)
Reflector
MM - MicroMatt
WR - White Enamel
Options
UNV - Universal Voltage Ballast
841 - 800 Series 41K Lamps
850 - 800 Series 50K Lamps
# Lamps
1
2
Lamp Watts
17
32
Photometrics - (1) 32W T8
22.25
3.25
ZONAL LUMENS AND PERCENTAGES
** EFFICIENCY = 84.5% **
PAINT REFLECTANCE = 0.78 S/MH = 1.40
SC (ALONG) = 1.23 SC (ACROSS) = 1.40
PREPARED IN PHOTOPIA FOR
ENERGY SOLUTIONS
ST. PAUL, MN
LUMINANCE SUMMARY - CD./SQ.M.
ENERGY SOLUTIONS 2 X 4 FLUORESCENT LUMINAIRE
WITH WHITE REFLECTOR AND BASKET LENS
ONE T8 LINEAR FLUORESCENT 32 WATT LAMP, LUMEN RATING 3000 LMS.
ONE SYLVANIA QT1X32QHE BALLAST OPERATING AT 277 VAC
