VX
LED Strip Fixture and Retrofit Kit
Installation
6.50
"
2.50
"
Technical Data
Housing: 20ga. (0.036") pre-painted die formed
steel with sufficient knockouts for mounting and
electrical supply.
Finish: All cold rolled steel parts are painted with
a smooth, glossy, highly reflective white paint.
Reflector: Can be ordered with a 95% specular,
a 85% specular, or a 92% diffuse white enamel.
Substrate is 0.020" high quality aluminum. The
reflector profile is optimized using computer anal-
ysis and manufactured using state of the art
CNC equipment. A protective premask is applied
to all reflective surfaces prior to manufacture.
Construction: The solid 0.036" steel body pro-
vides added rigidity. The socket bars and end-
plates securely snap into place. The reflectors
are attached to the fixture body with a tab-lock /
quarter-turn system.
Features
Energy efficient replacement for fluorescent
technology
100,000 hr.+ L70
Dimming option available upon request
Wide range of lumen and wattage packages
available
Meets or Exceeds
1598 Standard
48.0
"
Series
Energy Solutions International
Ordering Information
K - Kit
14VX - 1' x 4'
Fr - Frosted Lens
F - New Fixture
18VX - 1' x 8'
Style
Size
Lens
Light Engine
Output
35 - 35K LED Color Temp
41 - 41K LED Color Temp
50 - 41K LED Color Temp
L4N - 4' LED 30 Watt
L4L - 4' LED 15 Watt
L4H - 4' LED 42.5 Watt
L26
