Retail
Recessed High Performance Fixture
Photometrics
Ordering Information
Case Study
250' x 250' x 14' Retail Space
Re ectances:
Ceiling 80
Walls
50
Floor
20
Luminaire:
ESI Performer 1' x 8'
(3) 32W FO32 T8 Lamps
Standard Power Ballast
Lightloss Factor: 0.80
Lumens / Lamp: 3050
Mounting
Height:
14'
Spacing:
Continuous
Rows, 12' on
Center
Results
Illuminance Level: 81.3 fc
(at 2.5' from oor)
Ave / Min
1.3
Max / Min
1.5
Watts / Sq. Ft.
0.91
Size
F-14RS - 1' x 4'
F-18RS - 1' x 8'
Part Number = Fixture Size + Re ector Material + # Lamps + Lamp Wattage + Voltage + Ballast Type
(Example F-18RSEA332277N = 1'x8' Recessed Strip with an enhanced aluminum re ector, 3-32W lamps, 277 volts, and a standard powe
r ballast)
Re ector
EA - Enhanced Alum
AA - Anodized Alum
WR - White Enamel
# Lamps
1*
2*
3
4
Lamp Watts
32
54
Voltage
120
277
Ballast
N - Standard
H - High Ballast Factor
L - Low Ballast Factor
* 1 and 2 Lamp option for 1' x 4' Fixture
(888) 308-9197
Series
Energy Solutions International
