Digital Microscope Cameras ● Ultra-Compact USB cameras with color CCD ● Hardware & Software Trigger USBCAM133 with a 1/3-inch color CCD. USBCAM152 with a 1/2-inch color CCD. USBCAM202 with a 1/1.8-inch color CCD. All three cameras are cased models with a rear mini-USB connector; hardware and software triggering image capture, digital zoom and a feature-rich user based menu setup and control. Sentech USB cameras include a SDK, DirectX, Twain and Linux driver, as well as the Sentech Viewing Software. USBCAM133 USBCAM152 USBCAM202 504570 504574 USBCAM152 1/2” Interline SXGA color progressive CCD 4.65 (H) x 4.65 (V) µm Progressive 1360 (H) x 1024 (V) 18 Lux at F1.2 Auto / Manual (software selectable) Auto / Manual (software selectable) Manual (software selectable) Auto / Manual / One shot (software selectable) USB 2.0 High Speed +5 Vdc through USB connector, < 420 mA 28 (W) x 28 (H) x 42 (D) mm (excluding connector) C mount Approximately 45g USB: mini-B USB connector IO signal: 6pin connector (HR10A-7R-6PB or equivalent) RoHS Compliant USBCAM133 USBCAM152 USBCAM202 USBCAM133 Image Sensor Cell Size Scanning System Resolution Min. Scene Illumination Electronic Shutter Gain Gamma White Balance Input / Output Power Dimensions Lens Mount Weight Interface Connector RoHS 1/3” Interline SXVGA color progressive CCD 3.75 (H) x 3.75 (V) µm Progressive 1280 (H) x 960 (V) 11 Lux at F1.2 Auto / Manual (software selectable) Auto / Manual (software selectable) Manual (software selectable) Auto / Manual / One shot (software selectable) USB 2.0 High Speed +5 Vdc through USB connector, < 300 mA 28 (W) x 28 (H) x 37 (D) mm (excluding connector) CS mount Approximately 45g USB: mini-B USB connector IO signal: 6pin connector (HR10A-7R-6PB or equivalent) RoHS Compliant Digital Microscope Camera, Digital Microscope Camera, Digital Microscope Camera, Replacement USB Cable, 3m (10 ft) CONN 6-PIN (external camera triggering control) USBCAM202 1/1.8” Interline UXGA color progressive CCD 4.40 (H) x 4.40 (V) µm Progressive 1600 (H) x 1200 (V) 7.7 Lux at F1.2 Auto / Manual (software selectable) Auto / Manual (software selectable) Manual (software selectable) Auto / Manual / One shot (software selectable) USB 2.0 High Speed +5 Vdc through USB connector, < 450 mA 28 (W) x 28 (H) x 42 (D) mm (excluding connector) C mount Approximately 45g USB: mini-B USB connector IO signal: 6pin connector (HR10A-7R-6PB or equivalent) RoHS Compliant MICROSCOPES, CAMERAS USBCAM33 / USBCAM50 Record images directly to your computer. These digital microscope cameras offer flexibility, with a range of configurations for image capture, a choice of mount option (C or CS) and file output alternatives. Since both cameras connect via the USB port, installing the image capture software is simple. Either camera can be used on WPI’s stereo microscopes PZMTIV, PZMTIII, compound microscopes W30ST and GPL-T and also the PSMT5 Surgical Microscope. Choose from the one third-inch CCD with 1024×768 resolution and 30 frames per second (USBCAM33) or one half-inch CCD with 1280×960 resolution and 15 frames per second (USBCAM50). USBCAM33 USBCAM50 503536 Digital Microscope Camera, 1/3-in. CCD Digital Microscope Camera, 1/2-in. CCD Cable, USB Extension (male-female) These cameras include IC Imaging Control 3.0 software that features: ● Real-time video preview ● Text and graphics can be drawn on a live video stream ● Scroll and Zoom ● Acquisition of single frames ● Capture pause, for intermittent image capture ● Timestamps USBCAM33 IMAGE SENSOR MAX RESOLUTION SIZE SPEED (PC DEPENDENT) SENSITIVITY EXPOSURE, SHUTTER CONTROL, WHITE BALANCE INTERFACE SYSTEM REQUIREMENT SOFTWARE LENS MOUNT CAMERA BODY WEIGHT 1/3” Sony CCD, progressive scan 1024 x 768 4.65 µm x 4.65 µm 30fps, 15fps, 7.5fps or 3.75fps 0.5 lux @ 1/15 s Automatic/Manual USB 2.0 cable Windows Vista (32 & 64 bit) or Windows 7 (32 & 64 bit) IC Imaging Control Software C/CS-Mount 50.6 x 50.6 x 50 mm 265 g (9.5 oz) USBCAM50 1/2" Sony CCD, progressive scan 1280 x 960 4.65 µm x 4.65 µm 15fps, 7.5fps or 3.75fps 0.5 lux @ 1/7.5 s Automatic/Manual USB 2.0 cable Windows Vista (32 & 64 bit) or Windows 7 (32 & 64 bit) IC Imaging Control Software C/CS-Mount 50.6 x 50.6 x 50 mm 265 g (9.5 oz) World Precision Instruments UK: Tel: +44 (0)1462 424700 • wpiuk@wpi-europe.com www.wpiinc.com Germany: Tel: +49 (0)30-6188845 • wpide@wpi-europe.com US: Tel: 941-371-1003 • sales@wpiinc.com 161
