Step-up rail
Further step-up rail lengths are available upon request!
25
1 Rail profile 2 Foot element 3 End cap 3
1
mm
118 m
mm
m
60 2.7
2
299 mm 275 mm 251 mm 227 mm 203 mm 179 mm
Finish: galvanised
Rail profile
• robust U-shaped profile from high quality steel • standard length of 2.760 mm • with anti-slip covering
Further lengths upon request.
Including anti-slip covering
Ref.no. (per pce) Finish: galvanised
36-27490
Foot element
• slotted joining plates to adjust height level of rail profile • solid floor anchors ensure high stability Delivery includes 1 U-type profile, 2 joining plates and 2 floor anchors.
Starter segment = 2 foot elements Extension segments = 1 foot element
Including fixing material and floor anchors
Ref.no. (per pce) Finish: Plastics (PP), black
36-27491
End cap
• prevents accidents by closing the open-ended short sides of the profile • tightly closing cap for a firm fit • attractive finish
Including fixings (self-drilling screw 5,5 x 19N)
Ref.no. (per pce)
36-27492
27
PRO system
FLEX system
• easy and safe access to upper shelving levels • can be adjusted to 6 heights (179, 203, 227, 251, 275 and 299 mm) • safe working due to anti-slip covering • starter and extension segments
|
