Individual components Framework construction with PRO uprights PRO system
Upright type S-P2
Uprights type S-P2 and S-P3
90 mm • robust, bolted frame construction • pre-assembled frames • high load capacities • uprights are available in two widths • high quality floor anchors ensure safe racking positioning • flow shelves are height adjustable in 12,5 mm increments
All components are supplied with fixing material.
25 mm
50 mm
1 Upright Upright type S-P3
By turning the support clip through 180°, flow shelf spacing can be regulated in 12,5 mm increments.
2 Horizontal strut 3 Diagonal strut 4 Base plate Finish:
galvanised
100 mm
25 mm
50 mm
Including floor anchors and base plates
Upright type S-P2; max. bay load 6.350 kg Frame depth (T) Frame height (H)= 2.505 mm 800 mm 911 mm 1.100 mm 1.511 mm Ref.no. (per pce) 36-24915 36-24919 36-24921 36-24925 36-24927
All components are galvanised.
*
2
Ref.no. 36-24926 and 36-24928 are supplied with unassembled frames.
*1.511 mm *1.711 mm
1.711 mm
*36-24926 *36-24928
36-24916 36-24920 36-24922 36-24917 36-24923 36-24918 36-24924
1
1 H 3 3 4
Frame height (H)= 3.005 mm 800 mm 911 mm 1.100 mm Frame height (H)= 3.505 mm 1.100 mm 800 mm 1.100 mm Frame height (H)= 4.005 mm 800 mm 1.100 mm
Including floor anchors and base plates
Upright type S-P3; max. bay load 8.900 kg Frame depth (T) Frame height (H)= 2.505 mm 800 mm 1.100 mm Frame height (H)= 3.005 mm 800 mm 1.100 mm Frame height (H)= 3.505 mm 800 mm 1.100 mm Frame height (H)= 4.005 mm 800 mm 1.100 mm Ref.no. (per pce) 36-24929 36-24933 36-24930 36-24934 36-24931 36-24935 36-24932 36-24936
2 T
