60
incremental encoder
HEDS compatible 2 channel encoder with index pulse
Standard line count 00 CPR (up to 120 CPR available)
Supply voltage V
Output voltage TTL compatible
Mounted to rear of motor
PBL60-78 with encoder pictured
Standard incremental encoder
Motor ranges
PBL42; PBL60; PBL86
Additional length
21 mm
Current consumption
typ. 60 mA with no load
Connections
-way socket for latching connector
300 mm fl ying leads available
Protection
IP30
encoder connector
Motor
·
A
·
Encoder
·
·
·
B
V
Index
GND
encoder output signals
A leads B for anticlockwise motor rotation
(positive connected to red lead on PM motors)
Index pulse is gated with A and B both low
A
B
Index (1/rev)
00/rev
anticlockwise
rotation
