4
See page 61 to specify shaft and gearbox position
input speed variable up to 4000 rpm; other ratios available on request
PBL60-138(IE)LWS
Ratio
Final speed (rpm)
Rated torque Nm
up to 4000 rpm
Peak torque Nm
up to 2500 rpm
15 min rating Nm
up to 3500 rpm
Worm
Spur
1500 rpm
69 W
2000 rpm
92 W
3000 rpm
138 W
4000 rpm
184 W
16 1/2:1
11:1
0.8
1.1
1.6
2.1
100
100
100
8 1/3:1
11:1
1.6
2.1
3.1
4.2
100
100
100
12 1/2:1
6:1
2.1
2.
4.3
.7
100
100
100
8 1/3:1
6:1
3.2
4.3
6.4
8.6
100
100
100
6 1/4:1
6:1
4.3
.7
8.6
11.4
100
100
100
12 1/2:1
2:1
4.8
6.4
.6
12.8
62
62
62
8 1/3:1
2:1
7.2
.6
14.4
1.2
6
62
62
6 1/4:1
2:1
.6
12.8
1.2
26
4
62
6
16 1/2:1
6:1
1.2
20
30
40
22
44
28
8 1/3:1
6:1
30
40
60
80
13.4
27
16.8
MOTOR
Brushless DC motor
PROTECTION
IP4 (IP0 at exposed rear motor shaft)
GEARBOX
Worm spur (LWS)
MOTOR POWER 6 - 184 Watts
SPEED
0.8 -80 rpm
VOLTAGE
24V DC (or 48V DC with IE model)
WEIGHT
. kg
CONTROLLER
B (or integral with IE model)
SHAFT TYPE
Single ended or double ended shaft as standard; 17mm
diameter shaft available with ratios 11:1 and 6:1
EXTRAS
Gearbox available without feet; unit can be mounted
on gearbox spigot; for further options see page 18
