PBL42 motor and controller pack
ages
General tolerance on data is +/- 10%; Values shown are at normal operating temperature unless stated.
PBL42 motor and controller pack
ages
5
3
DIMENSION 'A'
4
2
FLYING LEADS
300mm ±10mm
3
5
-
0
.
0
5
0
.
0
0
-
Ø
33
7.938
7.925
Ø
4.3
7.927
7.920
Ø
5
42.3
8 HOLES Ø4.29
EQUI SPACED
ON A Ø41.3 P.C.D
10mm DEEP.
CAN BE TAPPED M5
OPTION: 4 HOLES Ø4.2
THRO' ON A Ø63.0 P.C.D
PBL42 motor data
Motor
PBL42-47
PBL42-67
PBL42-87
PBL42-107
Controller
S
S
N
B
Max rated speed
rpm
4000
4000
4000
4000
Rated torque
Nm
0.062
0.12
0.17
0.2
1 minute rating
Nm
0.078
0.16
0.23
0.31
Peak torque (duration 6 seconds)
Nm
0.12
0.2
0.37
0.
DC bus voltage nominal
V
24
24
24
24
DC bus voltage min-max
V
16-32
16-32
16-32
16-32
DC bus current at no load and max rated speed
A
0.2
0.27
0.34
0.42
DC bus current at rated torque and max rated speed
A
1.8
3.3
4.3
Controller cont. current
A
2.
7.
10
Controller peak current
A
10
1
20
P
arvalux standard flange/mount and shaft
1 0
2.0
0.0
1.0
0
1000
2000
3000
4000
speed (rpm)
intermittent operating region
continuous operating region
1 minute rating
multiple of continuous torque
The controllers we supply are matched for each motor in
the range and tested as a pair with the motors during pro-
duction.
They operate from a 24V supply and have an analogue in-
put for motor speed, an input for forward/reverse direction
and a pulsed output to indicate motor speed.
Most models have an additional input for enable/disable
and an output indicating a fault condition.
·
·
·
Torque/speed characteristics
