arvalux standard flange/mount and shaft
PBL86 motor and controller pack
ages
Motor
PBL86-91
PBL86-91
PBL86-118
PBL86-145
Controller ref.
50B
B
50B
50B
Rated speed
rpm
3000
3000
3000
3000
Max speed
rpm
4000
4000
4000
4000
Rated torque
Nm
0.7
0.7
1.1
1.4
1 minute rating
Nm
0.
0.8
1.
2.1
Peak torque (duration 6 seconds)
Nm
1.4
1
2.2
2.8
DC bus voltage nominal
V
24
48
48
48
DC bus voltage min-max
V
16-32
36-8
16-8
16-8
DC bus current at no load and rated speed
A
1.1
0.6
0.8
1
DC bus current at rated torque and rated speed
A
11.8
.
8.7
11.2
Controller cont. current
A
2
10
2
2
Controller peak current
A
0
20
0
0
PBL86 motor data
speed (rpm)
torque (Nm)
Torque/speed characteristics
Dotted line shows performance limit on 24V DC bus.
0
0.
1
1.
0
1000
2000
3000
4000
0
0.
1
0
1000
2000
3000
4000
0
0.
1
1.
2
2.
0
1000
2000
3000
4000
0
0.
1
1.
2
2.
3
0
1000
2000
3000
4000
PBL86-91 24V
PBL86-91 48V
PBL86-118 48V
PBL86-145 48V
intermittent
operating region
continuous
operating region
1 minute rating
intermittent
operating region
continuous
operating region
1 minute rating
intermittent
operating region
continuous
operating region
1 minute rating
intermittent
operating region
continuous
operating region
1 minute rating
General tolerance on data is +/- 10%; Values shown are at normal operating temperature unless stated.
Most models have an additional input for enable/disable
and an output indicating a fault condition.
PBL86-118 and 14 motor and controller packages will
operate from 24V supply with a rated speed of 2000rpm.
·
·
The controllers we supply are matched for each motor in
the range and tested as a pair with the motors during pro-
duction.
They operate from a 24V or 48V supply and have an ana-
logue input for motor speed, an input for forward/reverse
direction and a pulsed output to indicate motor speed.
·
·
