EYE NUTS
(for attachment to threaded rod)
PART #
SIZE
VAN 29740024
For 1/2" rod
VAN 29740032
For 5/8" rod
VAN 29740040
For 3/4" rod
HEX NUTS
(zinc plated - fits threaded rod)
PART #
LENGTH
INF HN2PC08
1/2"
INF HN2PC10
5/8"
INF HN2PC12
3/4"
WASHERS
(for attachment to threaded rod)
PART #
SIZE
INF PW2P08
1/2"
INF PW2P10
5/8"
INF PW2P12
3/4"
U-BOLT CLIPS
(for securing cable ends)
PART #
SIZE
VAN 29010012
3/16"
VAN 29010016
1/4"
VAN 29010020
5/16"
THREADED RODS
(zinc plated - 10' long)
PART #
SIZE
INF TR2PC08120
1/2"
INF TR2PC10120
5/8"
INF TR2PC12120
3/4"
CABLING AND BRACING SUPPLIES
· Galvanized forged steel, national coarse
· Diameter shown indicates threaded rod size
THIMBLES
· Used for installing cables
· Thimble size should match the cable size
VAN 29050016
1/4"
VAN 29050020
5/16"
VAN 29050024
3/8"
QUICK LINK
· Quickly and easily connects components
· Zinc plated
VAN 29180020
5/16"
M.W.L 1,760 lbs.
GALVANIZED CABLE
· 5/16", 7-strand galvanized cable
· 250' roll
· Grade 50, very pliable
UNA 5101230031
3,200 lbs. strength
J-LAGS
· J-shaped hook with coarse threads which is
used to anchor cables to trees
CHH SP13835
3/8" x 4" Right
CHH SP13836
3/8" x 4" Left
CHH SP12380
1/2" x 6" Right
CHH SP12381
1/2" x 6" Left
CHH SP13837
5/8" x 7" Right
CHH SP13838
5/8" x 7" Left
GENERAL USE
33 CC CHAINSAW
· Throttle lock start position
· External access holes allow easy
carburetor adjustment
· Automatic chain oiler
· Handles and grips are proportioned for
optimum comfort
· Inertia chain brake / electronic ignition
· 1.4 kw / 1.9 hp power rating
· 50:1 fuel / oil mixture
· 33 cubic cm displacement
· 3/8" / 0.050" chain pitch / gauge
· 11,500 RPM maximum engine speed
· Standard equipment included:
16" chain (528 092 657)
16" guide bar (442 040 661)
Chain cover (952 100 633)
Universal wrench (941 716 131)
MAK DCS34116
13.3 oz. / 8.0 oz. fuel / oil tank cap.
PRO 3600 SERIES
SAFETY CHAPS
· 3600 TCS rated safety pad with Dupont Kevlar
· Contoured design safety chap with three quick
release buckles
· Attached belt with fold down length option
· One size fits all
CSW P008
38"
PRO 3600 SERIES
SAFETY PANTS
· 3600 TCS rated safety pad with Dupont Kevlar
· Contoured high back fits comfortably into the
lower back area to keep sawdust out and
kidney area warm
· Safety pad extends 4" above the crotch on
each thigh to provide critical coverage to large
artery areas of the upper leg
· Triple bartacking provides strength in high
stress areas
· 100% polyester outer shell
CSW P0012830
28 - 30
CSW P0013032
32 - 34
CSW P0013638
36 - 38
CSW P0014042
40 - 42
CHAINSAW PANTS
· 4100 threshold chain speed safety pad with
Dupont
TM
kevlar
· Continuous coverage from inseam to outseam
plus 4" to the left side of each leg
· Pants are specifically designed for slashing
· Full-wrap backpad, 600 denier polyester front
and beltloops
· Available in sizes 28 - 44
CSW M002(size)
