PYGMY FLOW METER
OUTFITS

· For accurate flow measurements in flows as
shallow as 3"
· Features a six-bucket wheel that is just 2"
in diameter
· Both headphones and digital styles meet
USGS type AA standards
· For mounting on a wading rod or
top setting rod

GUR 625CF8N

Rod with digital indicator

GUR 625DT4N

Top setting rod with digital

indicator

GUR 625AF8N

Rod with headphones

GUR 625AT4N

Top setting rod with

headphones

PLANKTON NETS

· Cone-shaped nets of 10 mesh, 153 micron
nylon cloth
· Minute plankton is collected and can be
observed in the removable, clear conical
graduated tube
· Net mouth is braced by a sturdy stainless
steel ring and harness
· Comes with two tubes

LAM 1063

15" x 5"

LAM 3-0023

38" x 12"

MINNOW TRAP

· Galvanized metal with ends that can be
nested inside each other for compactness
· Easy to open

BEL MT42

16" L

1.4" Mesh

BEL EXTRACLIP

12 pack

KICK-NET

· 1 m x 1 m square, 500 micron white mesh
· Hemmed sides for poles
· Reinforced bottom seam for anchoring

LAM 0021
LAM 0021-P

W / poles

STREAM GAUGES

· Instantly allows water level to be seen
· Fibreglass stream gauge is the best permanent
marker for water depths of rivers, streams,
lakes, ponds and swamps and will not rust,
rot or corrode
· Easy to read at long distances and protected
with a non-glare coating and stainless
steel fasteners
· Graduated in m, dm and cm
· Mounting hardware included with all gauges

CEP 99051

0 m - 1.22 m

CEP 99052

1.22 m - 2.44 m

CEP 99053

2.44 m - 3.66 m

WATER DEPTH INDICATOR

· Recommended for measurement of the level
of groundwater
· Touches the water's surface with a high grade
steel electrode, lighting up a highly visible

signal lamp on the cable reel while sounding a
loud buzzer
· Graduated in cm with running figures each
in dm and m
· Non-rusting cable conducts the current
through two embedded strands, sending the
electrode pulses to the signal lamp
· 3/8" cable
· Use with 4 C-cell batteries

INDICATOR

PART #

LENGTH

SPO 24146

30 m

SPO 24150

50 m

SPO 24156

100 m

SPO 24160

150 m

SPO 24164

200 m

SPO 24165

300 m

REFILL LINES

SPO 24148

30 m

SPO 24151

50 m

SPO 24158

100 m

SPO 24162

150 m

SPO 26520

200 m

SPO 24166

300 m

WATER SAMPLER

· 1 L clear acrylic sampler
· Furnished with a 20 m calibrated line and a
lead collar
· Brass messenger triggers release
· Built-in side outlet and flexible tube allows for
removal of water sample

LAM 1077

WATER SAMPLER WATERTRAP

· Lower messenger and retrieve sample
· Easiest determination of sediment load
· Cable operated; works at any depth
· Stainless steel construction

EIJ 12.02

VAN VEEN GRAB

· Used for taking disturbed samples from the

bottom of lakes, rivers, etc.

· Fastest indication of sediment type
· Four sizes to suit any need
· Inert stainless steel construction

EIJ 04.30

MULTIPARAMETER PROBE

· Instant determination of ground water quality

values in situ

· Portable, compact design
· Detachable probe made of high quality

stainless steel and measuring tape enables
precise depth readings within a one cm
accuracy

· Unit will respond to water contact with a lamp

and tone, which can be switched over to the
LCD display with a simple touch of a button

EIJ 13.38.SA
