MULTISCALE "SCALER"
· Unique pocket-sized set that includes all 24
standard architect and english/metric engineer
scale ratios
· Six leaves, precision printed both sides on
white laminated vinyl with the following scales:
Architect: 3, 1 1/2, 1, 3/4, 1/2, 3/8,1/4, 3/16, 1/8,
3/32, 1/16, 1/32 inches/foot
Engineer english: 10, 20, 30, 40, 50, 60 parts/inch
English/metric: 20, 33-1/3, 40, 50, 80,100
parts/meter
FOS 47213
MULTISCALE "QUADRANGLE"
· Ultimate pocket-sized set of map scales
including the 12 most commonly used for
measurement of distances on topographic
quadrangle maps and aerial photographs
used worldwide
· Six leaves, precision printed both sides on
white laminated vinyl with the following scales:
1:10,000 (10 cm = 1 km)
1:12,000 (1" = 1,000')
1:15,840 (4" = 1 mile)
1:24,000 (1" = 2,000')
1:25,000 (4 cm = 1 km)
1:50,000 (2 cm = 1 km)
1:62,500 (1" = 1 mile)
1:63,360 (1" = 1 mile)
1:100,000 (1 cm = 1 km)
1:125,000 (1" = 2 miles)
1:250,000 (1 cm = 2.5 km,1" = 4 miles)
1:500,000 (1 cm = 5 km, 1" = 8 miles)
FOS 47208
METRIC AREA DOT GRIDS
· Reads areas on maps and aerial photos
directly in hectares
· Dots and squares stand out on transparent
plastic grid
· Used for maps with a 1:10,000 or
1:20,000 scale
· 8" x 10" grid
DGR 10006
25 dots per square cm
DGR 10038
4 dots per square cm
DGR 10044
36 dots per square cm
MODIFIED HECTARE
DOT GRID
· For use on maps or photos of any scale
· Place grid over area to be measured, count
the dots and multiply by converting factor
listed on grid to obtain area
· 7-3/4" x 7-3/4" grid
DGR 20073
9 dots per square cm
