DIAMETER TAPES
· Steel diameter tape with claw hook
· Bright graduations on light colour steel tape
· Comes in PVC coated case
· Diameter maximum is 1/3 of linear length
FRR 385D5M
5 m
FRR 385DA5M
Refill
FRR 385D75M
7-1/2 m
FRR 385DA75M
Refill
DIAMETER TAPE
· Gray ABS casing
· Automatic and tape-free rewind
· Approximately 5 cm blank space before zero
· 6 mm wide tape steel protected against
abrasion by transparent burnt in lacquer
FRR 20MD
2 m
STEEL DIAMETER TAPE
· Graduated in standard cm / mm on one side
and the other side in consecutive cm / mm
of diameter
· Tape measures a maximum diameter of 1/3 its
total length
LUF C106TPM
6 m x 10 mm
LUF RC106TPM
Refill
SHORT STEEL
DIAMETER TAPE
· Available in metric and imperial
· Metric tape is marked in cm / mm on one side
and mm of diameter on the other
LUF W606PM
2 m - measures diameter up to 61 cm
LUF W606PD
6' - measures diameter up to 24"
FIBREGLASS METRIC
DIAMETER TAPES
· Fibreglass tape with claw hook
· 16 mm with one side graduated in cm / mm
and the other in diameter
· Diameter maximum is 1/3 of linear length
FRR 283D5M
5 m
1.6 m dia.
FRR 283DA5M
Refill
FRR 283D75M
5 m
2-1/2 m dia.
FRR 283DA75M
Refill
LONG SERIES
TAPE MEASURES
· Rubber comfort grip
· Nylon coated steel blade
· 3:1 gear ratio for quicker rewinding
· Imperial / metric
PRM T2240
50' / 15 m x 1/2"
PRM T2245
100' / 30 m x 1/2"
POLE TAPE
· 23" diameter tape and 72" linear
· 10ths on one side and 16ths on the other side
· Front and back graduations allow the
user to determine both the length and diameter
on the timber
· Chrome steel line with black markings
UTP 68610
1000 SERIES HI-VIZ
®
POWER
RETURN MEASURING TAPE
· Lightweight, high strength Hi-Viz
®
case is
easy to find on the job
· Fits easily into most tape holsters
· Bright yellow blade has clear
easy to read numerals
· Toggle lock is positioned for convenient
operation and holds the blade securely in
any position
· Virtually unbreakable Quad Hook
TM
; four rivets
for extra strength (1" blade only)
· Cushioned blade return
· Removable belt clip
LUF HV1012
1/2" x 12'
A1 blade
LUF HV1035CME
3/4" x 16'
A13 blade
LUF HV1048CME
1" x 26'
A30 blade
LUF HV1049CME
1" x 30'
A30 blade
LUF HV1312
3/4" x 12'
A2 blade
LUF HV1316
3/4" x 16'
A2 blade
LUF HV1325
3/4" x 25'
A2 blade
LUF HV1425
1" x 25"
A5 blade
LUF HV1430
1" x 30'
A5 blade
HI-VIZ
®
UNIVERSAL
MEASURING TAPE
· High impact, Hi-Viz
®
orange polystyrene case
· Yellow clad blade .005" / 0.13 mm thick
· Easy wind nylon drum
· Easy to read black and red markings
· Hook ring is retained neatly in the contoured
mouth of the case
· Removable belt clip
· Metric-English tape measures have a
two-sided end hook for use with either scale
· Lightweight
· B8 style blade
LUF HV15CME
3/8" x 50'
LUF HV30CME
3/8" x 100'
