GOLD SCREW
AUTOMATIC PANNER
· Separates gold from concentrates in less than
a minute
· Bowl angle and water pressure adjustments
control advancing material up the spiral riffles
· Driven by a 12 volt DC motor and pump
· Trash chute and overflow hose included
KEE GSW
GOLD PANNING KIT
· Contains:
Plastic sieve
Snuffer bottle
2 glass sample vials
Black sand magnet
14" ABS plastic gold pan
KIT 12195
GOLD FEEDER
· Separates concentrates 10X faster
· Processes up to 70 lbs. per hour
· Lightweight aluminum fold up construction
KEE GFI
DEEP POT MAGNET
· Manufactured with Alcomax III (magnet), mild
steel (body), and aluminum (spacer)
· Can be used in temperatures up to 220°C
PART #
DIAMETER &
HEIGHT
THREAD
SIZE
MAX. PULL
ECL 829
9.5 mm x 15.1 mm
M3
1 kg
ECL 830
12.7 mm x 15.9 mm
M4
2 kg
ECL 831NF
17.5 mm x 16 mm
10-32 UNF
2.65 kg
ECL 832NF
20.5 mm x 19 mm
10-32 UNF
4 kg
ECL 833NF
27 mm x 25 mm
10-32 UNF
6.1 kg
ECL 834NF
35 mm x 30 mm
10-32 UNF
14.75 kg
POCKET MAGNET
· Manufactured with Alnico
· Can be used in temperatures up to 550°C
PART #
SIZE
WEIGHT
MAX.
PULL
ECL E802
22.2 mm x 25.4 mm x 7.9 mm
.03
2.4 kg
ECL E803
27 mm x 35 mm x 15.9 mm
.09
4 kg
PLASTIC ACID BOTTLE
· Drip-proof threaded cap
VCR 12158
1 oz.
SNUFFER BOTTLE
· Collects small pieces of gold
VCR 12345
2 oz.
LSM 12202
4 oz.
GEOLOGY STUDENT
FIELD KIT
· Contains:
Pencil magnet
Pin probe
Streak plate and glass plate
Packaged in a geochemical soil sample bag
10X lens
KIT 12280
MINI-UV LAMPS
· Nylon strap is attached for easy carrying
UVP 95015801
SW
UVP 95012501
LW
UVP 95018801
SW/LW
Multiband split-tube
PORTABLE UV LAMPS
· Portable UV lamps are made of lightweight
durable plastic
· Battery charger included
UVP 95000902
SW
UVP 95001101
LW
UVP 95001002
SW/LW
Multiband split-tube
RECHARGEABLE UV LAMPS
· Internal gel-based, lead-acid battery, which
can be charged for field operation from a
standard wall outlet
· 12V adapter is available for operating the lamp
from a car cigarette lighter
· Rechargeable lamps have two tubes for added
UV intensity
UVP 95018701
SW
UVP 95018601
LW
UVP 95018101
SW/LW Multiband split-tube
LEATHER CASE
· Quality leather case for acid bottle
GFL ABCM
