COARSE SAND AUGER
· For use in coarse sandy soils that have little or
no cohesion
· Blades are extended with extra wings, thus
forming an almost closed auger that will firmly
keep hold of loose material
EIJ 01.01.04.07.1
7 cm
One piece
EIJ 01.02.04.07.B
7 cm
Bottom
EIJ 01.10.07.B
1 m
Extension w/
bayonet coupler
EIJ 01.10.01.B
Handle only w/ bayonet
connection sleeve
· Recommended for use in all soil types
except sandy and rocky soil
· 1-1/4 m in length
· 2-1/2 lbs. to 5-1/2 lbs., depending on model
EIJ 01.01.02.04.1
4 cm
One piece
EIJ 01.01.02.05.1
5 cm
One piece
EIJ 01.01.02.06.1
6 cm
One piece
EIJ 01.01.02.07.1
7 cm
One piece
EIJ 01.02.02.04.B
4 cm
Bottom
EIJ 01.02.02.05.B
5 cm
Bottom
EIJ 01.02.02.06.B
6 cm
Bottom
EIJ 01.02.02.07.B
7 cm
Bottom
EIJ 01.10.07.B
1 m
Extension w/
bayonet coupler
EIJ 01.10.01.B
Handle only w/ Bayonet
connection sleeve
BUCKET AUGER (RIVERSIDE)
· Suitable for augering in hard, stiff soils mixed
with fine gravel, both above and below ground
water level
· Auger body consists of (1) iron tube with (2)
very sharp bits at downward angles
EIJ 01.04.00.05.B
5 cm
Bottom
EIJ 01.03.00.07.1
7 cm
One piece
EIJ 01.04.00.07.B
7 cm
Bottom
EIJ 01.04.00.10.B
10 cm Bottom
EIJ 01.10.07.B
1 m
Extension w/
bayonet coupler
EIJ 01.10.01.B
Handle only w/ bayonet
connection sleeve
COMBINATION AUGER
GOUGE AUGER KITS
· Often used in profile research for surveying
purposes, soil assessment and
rootage surveys
· Standard gouge augers are suitable for use in
soft soils
· Heavy-duty gouge augers are for use in hard
soils such as loam and stony soils
· Advantages of gouge augers by comparison to
other types of hand augers:
Better and longer soil profile
Faster operation
Undisturbed soil samples
SOFT SOIL
· Suitable for peat, clay and sandy soils
· 50 cm and 100 cm operational lengths
· Includes:
(2) regular single gouge augers
(1) spatula
(1) carrying bag
EIJ 04.01SA
HARD SOIL
· Includes:
(1) gouge auger with a heavy-duty auger body
(1) impact absorbing steel hammer
(1) bent spatula
(1) carrying bag
EIJ 04.01.SB
BI-PARTITE GOUGE
AUGER SETS
· Samples depths to 5 m
EIJ 04.02SA
Soft soils
EIJ 04.02SB
Soft soils w/ conical
screw connectors
EIJ 04.02SC
Hard soils w/ beating head
/ hammer
BASIC HAND AUGER SET
· Samples and drills cohesive soils up to 6 m
and non-cohesive soils until the water table
· Copes with all soil types except bedrock and
water saturated sands
· During drilling, up to four rods can be kept
connected to speed up drilling and
sample retrieval
· Bayonet coupling enables the mounting of
other tools
· Includes:
Dutch augers to sample humid soils in a
semi-disturbed way
Riverside and stony soil augers
Durable carrying bag
Universal and super rapid bayonet coupling
EIJ 1.16
GOUGE AUGER SET
· Extremely slim auger bodies; low friction
· Can sample medium to harder soils
· 1 kg of tools
· Perfect for chemical sampling in the root zone
EIJ 04.06
HAND-OPERATED BAILER
BORING AUGER SET
· For heterogeneous soils
· Utilized in exploratory augering and sampling
and is also very suitable for installing well pipes
· Permits augering up to 7 m
· Contains augers for any type of soil above and
below the groundwater table
· Bailer removes the soil under the casing tubes
thereby allowing augering at a desired depth
· Designed for a one man operation
· Digs 7 cm or 10 cm holes
· Includes casing tubes and platform
· Comes in (2) aluminum transport cases
EIJ 01.12SA
SINGLE ROOT AUGER
· Takes undisturbed samples for root
investigations in soils with low penetration
resistance
· Samples with a length of 15 cm can be taken
to a depth of 1 m maximum.
EIJ 05.01
