STONY SOIL SAMPLER
· Sampler bits are bent outward to capture
stones between the blades so that they are
lifted from the sampling hole
· Recommended for soils with gravel content
too high for use of the bucket auger
EIJ 01.05.00.07.1
7 cm
One piece
EIJ 01.06.00.07.B
7 cm
Bottom
EIJ 01.10.07.B
1 m
Extension w/
bayonet coupler
EIJ 01.10.01.B
Handle only w/ bayonet
connection sleeve
SOIL CORING KIT
· Samples depths to 5 m
· For determining the presence of very volatile
components such as benzene, toluene, xylene
and chlorinated hydrocarbons
· Sample does not come in contact with any
synthetic material and meets the
NEN5743 specifications
· All exposed parts are stainless steel which
greatly reduces volatilization and oxidation of
components in the sample
· Can also be used for volumetric sampling of
water in soil
EIJ 04.16
LINER SAMPLER FOR
UNDISTURBED SAMPLING
· Undisturbed soil samples can be taken in a
liner to a depth of up to 7 m
EIJ 04.15SA
Soft soils
EIJ 04.15SB
Hard soils
AUGER SET FOR
HETEROGENEOUS SOIL
· Suitable for manual augering, sampling in
a wide variety of soil types for the purpose of
general soil research and sampling in
environmental research
· Standard set drills to 5 m
· Includes piston sampler to sample water
saturated sands
EIJ 01.11SO
SOIL SAMPLING AND
CLASSIFICATION SET
· Ideal for investigations down to a depth of 2 m
· Includes:
7 cm combination type auger
3 cm gouge
40 mm liner sampler
Hellige pH indicator
Soil colour book
Pocket penetrometer
Pocket vane tester
Mini hand sieves - 2.0 mm, 1.0 mm, 0.500 mm,
0.250 mm, 0.125 mm and 0.063 mm
Sand ruler acc. ASTM 11 - 63, 90, 180, 250, 355,
500, 710, 1000, 1400 and 2000 microns
Optional additional augers for other soil types
EIJ 08.15
SEDIMENT CORE SAMPLER
· No loss of sample in any case and piston
assures core sample length (sample lengths
up till 150 cm)
· Cutting head can be closed with air pressure
· Can be hammered to sample all sediments
· Contaminant-free stainless steel body
EIJ 04.23.SA
SPLIT TUBE SAMPLER
· Used for rapid undisturbed sampling at
the surface
· Suitable for research on root systems,
fertilizing and soil biology
· Includes:
40 cm split tube sampler
Beating head handle
Hammer
Sample liners
Storage containers
Steel lifting jack with lever and chain
EIJ 04.17
PEAT SAMPLER
· Stainless steel construction ideal for sampling
soft peat, slightly cohesive sediments, pastes
and dry or wet powders at a maximum depth
of 10 m
· 5 cm x 50 cm samples
· Flap prevents the sample from falling out of
the sampler
· Excellent for profile descriptions, paleontology,
biology and environmental
· Operates with universal conical screw
thread connections
· Works in water saturated as well as
unsaturated materials
· Supplied with combination type auger for
pre-drilling in peat soils and sturdy case
EIJ 4.09
SOIL SAMPLE RING KIT
· Samples can be taken in virtually all soils,
on the surface, in auger holes up to 2 m, or
in profile pits, above or below
groundwater level
· The closed ring holder can be hammered
into the soil with an impact
absorbing hammer
· Applications:
Water and air permeability
Moisture content at various tensions
Weight by volume
Density
Oxygen diffusion
Pore distribution
Soil-water-air relationships
EIJ 0753SC
SOIL MOISTURE METER
· Versatile Thetaprobe system which measures
and stores data
· Push probe, read and store
· Can be extended with profile probe and
conductivity sensor
· Two standard calibrations, three user curves
EIJ 14.26
RAIN GAUGE
· Measures intensity of rain over certain periods
as well as totalled amounts (integrator
function)
· User defined measurement periods
possible to measure both peak intensity and
precipitation averages over longer periods
of time
· Data gathered by rain gauge with the data
logger can be processed further in user's PC
EIJ 11.41.21.SA
